What Is an AnimationFrame and What Can It Tell You?

Today, I'm going to be talking about animation frames and what can it tell you, and also about the long animation frame API, LOAF, although very nicely, many say it's LOAF, yeah? Why not? Yes, my name is Vinicius, and I'm a lead engineer at PlusOne, also building PerfLab and PerfAgent. And modern web applications need to be responsive and smooth, providing users with immediate feedback for their interactions. So to understand how our applications perform, we need to understand how browsers process and render content. We want to treat our users well and bring exciting new experiences without junk or frustrations.

So building applications can be very hard, and shipping experiences that are smooth and responsive can be very difficult. This is why the Chrome team shipped INP as a metric and long animation frames as an API, to help us better understand and keep track of our users' experience. We'll be talking about some core concepts from browser internals and APIs. So for a catch up on how the event loop and some of those concepts work, there's a very good video from Lydia Haley called JavaScript Visualized that goes into great depth, explaining them in a very approachable way. But let's just take a little bit of time to get to know the basics about the long tasks and why we have a 50 millisecond budget for tasks to be executed in the main thread.

About 10 years ago, in 2015, the Rail team made popular a set of timings and gave us guidelines to keep us, to help us and keep the user's interactions smooth and responsive. So the 100 millisecond window you see in the image, it represents the total amount of time that the browser has to process any given input. But since processing also involves the event loop queuing and input and dispatching the event listeners, tasks are left with a 50 millisecond budget to execute a new domain thread to allow browsers to ship the next frame and serve a 60 frames per second experience. Any task that exceeds this budget may incur visual jank, delaying visual updates for the user.

For even more backgrounds on the history behind interactivity metrics, you can check another one of my talks called Long Frames and INP, Understanding the Postload Performance. So now, back to long tasks. Though the Rail model introduced us to the concept of a long task, the long task API has a major problem. Though it allows us to collect long tasks that happened over a span of time, its attribution model fails to give us a proper insight over which scripts or functions those tasks may come from, giving us not much more than timestamp and blocking duration time. So we don't really have a good way to understand why those long tasks happened and where those bottlenecks are coming from. So this quote is actually taken from the Google article around the Long Animation Frame API, explaining exactly that such problem from the long task.

Another important point is that if you only consider long tasks as a source of interactivity problems, you're eliminating an entire class of performance problems that has to do with styling and layout. So those can also prevent the browser from responding to interactions and slowing down the production of new frames. So this interaction here on the image, it has a long processing time, but it mostly comes from forced layouts and styling. So this can also incur visual jank. This is why we now have animation frames as the base model that powers INP and long animation frames. So in this talk, we will be checking out the concept around how the browser processes different events and how those events affect different parts of the animation frame, impacting users' experience and URNP score.

An animation frame represents the complete cycle the browser performs in order to process events and present new frames on the screen. This process may include works such as queuing and processing possible user input, executing code, tasks or micro-tasks, processing style and layout, and finally, composing and rendering a new frame. So think of an animation frame as a snapshot of all the work needed to generate visual updates for your users. The work performed in an animation frame is used as an attribution for the three parts of the INP score, which are input delay, processing time, and presentation delay. But from an animation frame perspective, this work can be measured and classified more granularly within its attribution model, and we will see more about that later. Animation frames are present session-wide and, although it is used as a base model for attribution towards INP, it does not require an interaction. It simply measures different types of work that happens before the browser could ship the next frame, collecting timestamps and separating them into different types of work. Because of that, it can be considered as a good candidate for an abstraction when it comes to how browsers process work and how users perceive their experience.

From an animation frame perspective, work is divided into different categories. So when you have timings, those categories are divided into the script compilation, script execution, style layouts, work, and render work. So each of them are aggregated into their own part of the attribution model of the animation frame.

Let's come back to this interaction. You cannot immediately tell why we're spending so much time on the layouts work and why are we spending so much of this processing time into rendering work. And since that's the main cause for why the processing time is so long, we would have to dig deeper into the flame graph to find the source of the problem.

It is also important to note that part of the attribution model may not be present in some animation frame, such as the missing attribution slots you have into the image there. That might be due to different limitations currently faced by the platform to accurately or safely infer the information, such as execution time coming from third-party scripts or Chrome extensions.

And underneath it, it shows the same segment, but highlighting the different sections of work executed in that animation frame. First, you may notice that we have multiple events in one single animation frame. I'll get back that I'll get back to it further ahead. But keep in mind that an animation frame and subsequently, IMP metric and the long animation frame entries are not limited to one event per interaction. So I can actually let me see if I can have this. There you go. So here is the same kind of segment within the performance tab. And you can see for this particular trace, you have different animation frames here, right? So within that, we can check, for instance, if I scroll for this particular animation frame, I have different types of work executed within one animation frame. And it's not always just scripting.

Now back to the presentation. It is also important to note that part of the attribution model may not be present in some animation frame, such as the missing attribution slots you have into the image there. That might be due to different limitations currently faced by the platform to accurately or safely infer the information, such as execution time coming from third-party scripts or Chrome extensions. So now let's take a look at different attributes from the animation frame attribution model, but how it's present into the IMP metric. You might have seen one of these little guys within the interaction track on the performance panel, where on the left and the right whiskers are the inputs and presentation delay. The solid bar in the middle is the processing time.

Let's start with the first UI event, timestamp. This is part of the attribution model within animation frames, coming from the Long Animation Frame API. But it also is known as the input delay. This is the timestamp for the first event, the first interaction event to be processed within a given animation frame. This timestamp represents the interaction event creation and might have happened at any point in time within the current or previous animation frame, depending if there was a delay between the event being created and the event being processed. These attribute provides the data used to calculate the input delay for animation frames that are connected to the IMP event. The processing time encompasses work on the main thread related to tasks or microtasks that are executed during the animation frame. If inspected in the profiler, this group of work will be represented on the flame graph by work such as script compilation, different function calls and callbacks, promise execution, timer callback functions, and also forced style and layouts.

The last section of work before the browser can produce a ship in the next frame is the presentation delay. It consists of any work related to processing visual updates needed after the main thread has finished executing all tasks of the animation frame. This type of work is composed of different parts like style and layout. But style layout is not the only type of work being processed at this stage. Other different APIs are executed between a task execution and the frame being presented on the screen. Work such as CSS selector evaluation and styling computation, precise observer callbacks, view transition promises, and request animation frame callbacks. The work executed at this stage runs a lot closer to the parts of the animation frame that involves presenting a new frame, but they also can contribute to delays before the new frame can be presented, since some of those APIs may also spawn its own microtasks, thus work executed at this stage can also lead to IMP problems.

So, why should we think in terms of animation frames? Back in 2021, in order to empower the next interactivity metric and improve the attribution model for our field data, the Chrome team started research and development around a new standard way of measuring work around user interactions. A year later, IMP became an experimental metric, and in March 2024, it replaced first input delay, FID. Alongside INP, we also got the long animation frames, which is how we started aggregating the INP phases into a new attribution model. So, in the form of animation frames, entries were exposed as part of the performance APIs through the long animation frames API, or LOAF.

Similar to the long task, let's see how the contrast is looking on this one. Okay, I think it's good enough. So, similar to how the long task API works, the long animation frame API exposes animation frames entries that are above 50 milliseconds thresholds, allowing developers to focus on collecting data that might point to bottlenecks around their applications. So, using again the power of annotations from the performance panel, I'm showcasing here a segment of a trace and each animation frame accounted for that segment. This showcases how we can better connect the work executed on the main thread to how visual updates actually are shipped and produced to the user, as we can better visualize how the browser processes work and produces frames.

Using such concepts, I've built a form of Instagram within PerfLab to showcase the distribution of animation frames according to statistics taken from its attribution model, enabling some exploration on how to quickly expose possible bottlenecks within your application on a session-wide scope. So, instead of focusing on one singular point in time based on your INP interaction, you get a better understanding of, or rather a holistic understanding of how your code executes and what kinds of different problems might be happening through the entire session. So, from the API side, the team behind Web Vitals released an update recently that enriches the INP attribution model with buckets. So, these buckets include the total time spent on different types of work performed by INP, the INP interaction. So, you would have a better understanding of how much time is being spent on your animation frame coming straight from the Web Vitals API.

So, let's come back here on this little demo. So, from this little histogram here, a form of histogram, I can see how much script and layout I'm having executed throughout different sections of time. So, I kind of split the entire timeline into different equal portions of work and I can quickly jump into different parts that might seem troublesome and get a better understanding of what's going on. So, this is not necessarily connected to any particular metric. It's just how my session is going overall. So, I can see here that I have a very long animation frame going on here and I can try to jump into the trace and get a better understanding of this.

Now, let's get back here. So, from the API side, the team behind Web Vitals released an update recently that enriches the INP attribution model with buckets. So, these buckets include the total time spent on different types of work performed by INP, the INP interaction. So, you would have a better understanding of how much time is being spent on your animation frame coming straight from the Web Vitals API. So, as we have established so far, the animation frame can happen session wide and they are a great abstraction we can use to measure and classify work needed to present a frame. So, now let's take a look on how interactions may influence animation frames. So, user interactions may be initiated at any time during an animation frame, taking consideration that animation frames are slots that happen session wide. So, if the event creation happens during the processing time section of an animation frame, the interaction event might be queued and allowed to follow its event handler. So, tasks during that...

So, it won't be within the same animation frame, which would represent the input delay that you see on the image here. But it is also important to separate the concept of interaction and event handlers. As one interaction might include multiple event handlers, such as the key down, key press, and key up events on a single keystroke instance. Each may have their own event handler's tasks to be processed. And in some cases, each event may even be processed over a different animation frame, which means that each event handler could either be part of the input delay or processing time from an animation frame perspective. That's why our NP event might incur multiple long animation frame entries. It is also important to remember that each long animation frame entry might have multiple scripts attributed to its execution time, as application and framework code may be connected to the same task being executed. User interactions are only a part of a larger context when it comes to how our users perceive their experience. Performance problems may have any combination of factors to why things might be slow. But understanding our user's perspective, for that, we need a larger context. And that often is lost if you only think about the individual pieces.

That's why animation frames can be a great candidate to help create a more productive discussion around performance problems, by consolidating all different types of work into a model that better represents users' perception, and helping development teams get more confidence and better workflow around their performance tasks. Animation frames are also really, really good, when it comes to attribution model, to give it to AI models.

So this is the PerfLab part. I also have created this little guy, which is a form of chat bot, you can say, where you can extract. I have to take a look at the size of these guys. Let's see this one. It is a chat bot, of sorts, where you can help identify performance problems. Where PerfLab was more of a dashboard per se, this is the smallest subset of what a dev tool can look like. And it's built on the same internals of Google Chrome, the developer tools.

So I extracted that, and generated the standard library that helps me visualize trace, and also extract that out of traces. So you have still INP here, and of course you have animation frames happening. Same kind of concept of the histogram. So it gives me a distribution of how the frames are looking like, and highlighting different problem areas. But also, I can ask, can you... This is hard to type. Can you help me understand my INP score on this trace? So the rich data you have in the animation frame data, attribution data, you can hand to a model, to a large language model, and help you better understand your performance problems as well.

So based on the data that I hand from the trace file, using the same internals as Google Chrome uses within the dev tools, where they also are interacting trace files and flame graphs, it's through different models to help you detect problems. It's the same concept here. I extract the same internals, and then generate a very in-depth report based on that one interaction that happens. You can extract the specific time it happened, you can help you visualize the interaction, and also visualize the flame graph, so you can better understand what's going on. And give you analysis based on that, and help you understand the problems that you're facing. And all of this is powered by the same data of the animation frame attribution model. So the rich attribution model we have, it really, really helps both us, and of course the machine gods to give us insights.

So this talk is based on a write-up that I have. So this is the QR code for the write-up that I have done last year for the Perf Calendar. Give you a little moment to snap it. And that is about it for me. Thank you all. So our first question. Yes. What kind of tools are there for analyzing task-related performances on web interfaces? Well, a really good one that you have... So if you're talking about APIs, you have, of course, the Long Animation Frame API. You will have the Web Vitals. So Web Vitals, the Core Web Vitals, and Web Vitals Scripts. It really helps you to gather information from your application on the Rome perspective, real user monitoring. It's really, really important to get that real user data. So either via your own scripts, reading straight up from the performance entries, your Long Animation Frame data or by the Web Vitals is a good way to do it. Or capturing traces as well. We have the self-profiling APIs, where you can capture traces to do it. Nice. Yeah. It seems like quite a complicated kind of thing to break down. It is, yeah. Actually, so how would you... What advice would you give for somebody looking at a flame graph like that for the first time to try and work out where things are going wrong? That's a good question. Right.

So the Chrome team has been on an absolute roll when it comes to helping developers of all sorts of expertise to better understand traces. So within the trace file, within the performance tab, you have the AI ask. So you can select a frame and you can have the AI panel popping on the console and you can ask the AI on boards of Chrome different questions about the trace. I'm building one myself. I think that's very cool. Being able to ask questions about it is one of the superpowers of AI models and their ability to look at a big set of JSON and pick out actually the interesting... Yeah.

Flame graph can be very scary at first. And what for professionals on the field of performance, especially, is information. For many people, it's noise. And getting to break through that barrier is difficult. So that's why I started creating the agent. And that's why Google Chrome is also imbuing the performance tab with AI. That's very cool.

How would you motivate a dev team to work with improving performance and utilizing tools like INP? And I'm going to keep calling it LOAF. Long animation frame. LOAF. It's a good way to call it. I have another article in another talk just about that. So it's why your performance work is not seen. And I would say the TLDR is work with metrics that are important for your product. So performance metrics, they are the general approach. They are how, in general, you should try to fix performance. And you have thresholds as well that will help you better understand different parts of performance. Or overall, help you shape a smoother experience.

And I would say the TLDR is work with metrics that are important for your product. So performance metrics, they are the general approach. They are how, in general, you should try to fix performance. And you have thresholds as well that will help you better understand different parts of performance. Or overall, help you shape a smoother experience. But ultimately, it depends a lot on what matters to your product. So if you have a more static web page, INP is not necessarily the best performance to try to fix. So consider how your product... What is the nature of your product? What metrics matter the most? And that's where you start. I was going to say, it's best to tie it to actual business metrics. Exactly. Right, right, right. Yeah. So if INP is important to your business, if people using and interacting with your applications is important, that's the thing. Yeah. Sweet.

Given your insights into performance analysis, if you encounter a performance issue, one of those big old long animation frames, are there any typical steps that you would approach for figuring out the cause? Yeah. So normally it's just dig straight. It depends on what kind of data you have. So if it comes from your Rome tool, some Rome tools have... If Sentry, one of the sponsors, they have actual traces. So that's significantly helpful. But if you're more limited to just metrics, then the first thing it would be to try to profile first. When you only have metrics, numbers, they tell you there is a problem, but not where the problem is. So you need more data. So that only can come through a trace file. Nice. OK. This might be a quick or an easier one.

This might be a quick or an easier one. What's the cross browser support looking like for long animation frames? So long animation frames currently are available on Chrome. Barry's right in front of me there. I'm not sure if it is widely supported yet. I haven't checked to be honest with you. I thought Barry might know that, but he's shaking his head he doesn't know. I put him on the spot there. But yeah, it's available on Chrome. I know that... I've read that Safari is working on shipping as well. So it's widely available. I assume that being in Chrome means it's an edge as well. Yeah, exactly. It's an edge as well. So any Chromium browser has it. So it's a pretty significant portion of users. Awesome.

We do have one little interlude into your agent chat bot. And somebody would like to know which LLM is used for the agent. Gemini. Gemini. All right, there you go. It's different agents. I'm orchestrating with different agents because data for a profile file is rich and very, very large. So there are different experts, agents that I'm building. One just for NP, one just for LCP. And then from that, I just hand different portions of the trace to each specialized agent. Yeah, very cool. Very cool. But it's Gemini.

It's Gemini. It's Gemini all the way through. Nice. Did you try a few out to get the right one? Yeah. Yeah, I did. But I mean, since I'm very deep embedded into the DevTools source code and they use Gemini and I could see how the prompts are worked out, I figured Gemini training probably would also have read more about the metrics I want to care about. So my system prompt actually is more tailored towards that and trying to focus the agent to answer performance-related questions. And it worked very well from the get-go.

Nice. And what I'm going to do, one more last one question because we're just kind of running out of time here. But I think this is interesting. Does this long animation frame, kind of framework, help understand performance issues in WebGPU as well as the web in general? It would help in a little bit. So the WebGPU code is not executed in the main thread. The WebGPU is executed in its own separate thread. So it would help you understand when that code would interact with the main thread. And also, if it produced any kind of presentation delay during the render part, then you would also be able to visualize the different timings. But when it comes to attribution within animation frame, I would say, not as much. Okay. Yeah. Fair enough. Yeah, the fact that it's handing off to something else, that makes sense. Yeah. Okay. Well, I'm going to cut that there. But I want everybody to give another thank you to Vinicius. Thank you.

There's a Q&A section now. You're heading downstairs to answer Q&A.
